This Operator’s Manual is for Link-Belt 245X4 Hydraulic Excavator. Contains the Operation, Maintenance information of your machine. You have purchased a dependable machine, but only by proper care and operation can you expect to receive the performance and long service built into this tractor. Please have all operators read this manual carefully and keep it available for ready reference. This Use and Maintenance Manual provides a guide for the user with regard to running-in, use and maintenance of the machine.
Type of Manual: Operator’s Manual
Total Pages: 251
Models Covered:
Link-Belt 245X4 Hydraulic Excavator
This X4 excavator is a fully hydraulic excavator. It consists of an undercarriage fitted with tracks and a turntable bearing which supports the upperstructure frame. The upperstructure frame supports the attachment, at the front end of the excavator, plus the engine, hydraulics and cab. When the operator works the controls, the engine-driven pump delivers hydraulic fluid to the control valve. The control valve distribute the hydraulic fluid to the various cylinders and motors concerned. A cooling system maintains the hydraulic fluid at normal operating temperature.
Manual Contents:
CHAPTER 1 – TO THE OWNER
CHAPTER 2 – EXCAVATOR COMPONENTS
CHAPTER 3 – SAFETY, DECALS, AND HAND SIGNALS
CHAPTER 4 – INSTRUMENTS AND CONTROLS
CHAPTER 5 – OPERATING INSTRUCTIONS
CHAPTER 6 – SERVICING INTERVALS
CHAPTER 7 – LUBRICATION, FILTERS, AND FLUIDS
CHAPTER 8 – MAINTENANCE AND ADJUSTMENTS
CHAPTER 9 – ELECTRICAL SYSTEMS
CHAPTER 10 – TRANSPORTATION & STORAGE INSTRUCTIONS
CHAPTER 11 – SPECIFICATIONS
INDEX
